Item
项目 |
Symbol
符号 |
Content
详细内容 |
Criterion
标准 |
|
过充保护
Over charge 1 Protection |
VCU1 |
过充保护电压
Over charge detection voltage |
4.25±0.025V |
|
tCU |
Over charge detection delay time
过充电检测延迟时间
|
||
|
VCL |
Over charge release voltage
过充电解除电压 |
4.10±0.05V |
|
|
Over discharge protection |
VDL |
Over discharge detection voltage
过放电检测电压 |
|
|
tDL |
Over discharge detection delay time |
1±0.5S |
|
|
VDU |
Over discharge release voltage
|
3.00±0.1V |
|
|
持续工作电流
Continue Current |
ICHG |
Continue charge current
持续充电电流 |
20A |
|
IDIS |
Continue discharge current
持续放电电流 |
50A |
|
|
过流保护
Over current protection |
OCIOV |
Charge overcurrent detection current
充电过电流检测电流 |
48A±15A |
|
ODIOV |
Discharge overcurrent detection current
放电过电流检测电流 |
180A±30A |
|
|
tDIOV |
Overcurrent detection delay time
过电流保护延时 |
400±50mS |
|
|
短路保护
Short current protection
|
ISHORT |
Short circuit detection current
短路保护检测电流 |
需客户提供电池 |
|
tSHORT |
Short circuit delay time
短路保护延时 |
/ |
|
|
过流/短路保护 恢复
Over Short current release
|
/ |
Over current & short current release
过流及短路保护恢复 |
Load disconnection |
|
温度保护 |
充电 |
充电温度保护值 |
70℃±5℃ |
|
放电 |
放电温度保护值 |
70℃±5℃ |
|
|
Balance function
平衡功能 |
VBAL |
Balance detection voltage（平衡工作电压） |
/ |
|
Balance release current（平衡电流） |
/ |
||
|
Balance Mode均衡方式 |
/ |
Eq Balanced working mode（均衡启动模式）
|
/ |
|
Internal resistance
保护板内阻 |
RCHG |
Resistance in charge 充电回路内阻 |
<10 mohm |
|
RDIS |
Resistance in discharge 充电回路内阻 |
<10 mohm |
|
|
Current consumption
静态功耗 |
ISTB |
Current consume in normal operation
工作时电路内部消耗 |
<30uA |
